VEOLIA Water Treatment – Sirion™ Advanced & Pro

SIRION™ Advanced & Pro reverse osmosis system produce high purity water, removing up to 98% of dissolved inorganics and over 99% of large dissolved organics, colloids and particles.

Specification

• • Low energy Membranes result in lower operating pressure; cost savings
  • Feed salinity up to 1000 mg/l TDS (NaCl)
  • 1 μm pre-filtration included within the unit for membrane protection
  • Dry run monitor; pump protection
  • Concentrate throttling valve for flow adjustment and concentrate recirculation
  • Instrument allocated in frontal control block part for comfortable accessibility and workability
  • Skid-mounted, standardized systems; short lead times, quick installation and start-up
  • CIP connections forwards installed
  • HMI Touchscreen 7” modern interface user friendly. Fully configurable and simple operation, monitoring of pressure, flow rate, conductivity and temperature values
  • AQUAVISTA™ compatible
  • Data logging
  • Comms via Modbus TCP or Aquavista
  • OPC Compliant

Materials

• Skid: Epoxy-polyester coated carbon steel
• Low pressure Pipework:
• PP Advanced model
• PVC-U Pro model
• POM piping (small ranges)
• High pressure Pipework: SS DIN 1.4404 ISO R1127

Options

• VFD for HP pump
• Conductivity/temperature sensor feed water
• pH measurement concentrate
• Acid/caustic dosing station
• Antiscalant dosing station
• Raw water automatic / manual blending
• Additional universal inputs / outputs
